Advantages

Main advantages



Safety and Health
– The system eliminates the usage of conventional gas cylinders and the possibility of explosion.
– The flame is environment friendly. The combustion of Hydrogen and Oxygen produces only water vapour, without any CO2 emission, resulting in a better working environment for the operators.
– The gas pressure is below than 0,5 BAR (< 10 PSI).
– No hydrogen storage, machine produces gas only on-demand.
– No toxic fumes from the flame.



Quality
– Automatic mixed gases, for a perfect stoichiometric ratio. No human error in brazing.
– Focused flame for less overheating.



Practicality
– Light and ergonomic torch for more confort in brazing.



Saving
– Brazing costs reduction.
– Two times faster brazing for a higher productivity.
– The system generates gas from distilled water.
– No gas costs.
– No gas transportation costs.

MODEL	HVACR	ELENC. MOTORS (repairs)	ELENC. MOTORS (manufacturers)	TRASFORMERS (bars)
30000HD	Pipe Ø max 140mm	Wires max 3000 mm²	Wires max 2000 mm²	Thickness: 15-16 mm Widht: 100 mm
20000HD	Pipe Ø max 110mm	Wires max 2000 mm²	Wires max 1000 mm²	Thickness: 10-12 mm Widht: 100 mm
10000HD	Pipe Ø max 65mm	Wires max 1000 mm²	Wires max 200 mm²	Thickness: 5-6 mm Widht: 100 mm
4600EP3F	Pipe Ø max 35mm	Wires max 150 mm²	Wires max 50 mm²	Thickness: 2 mm Widht: 100 mm
2500EP	×	Wires max 50 mm²	Wires max 15 mm²	Thickness: 1 mm Widht: 100 mm
Nota: Indicative values considering the gas generator at the maximum power, 1 torch fed.
